Edge Blending Processor


  1. The term 'edge blending' means that the overlapped edges need to be carefully processed to blend together without appearing any brighter than other regions or at least until the brightness difference is less easily noticed by viewers.
  2. DXN5500-4U Video Wall Controller. The DXN5500 video wall controller for walls made of beam projectors that need soft edge blending service. This processor drives the wall of multiple projectors, draws Windows 10 compatible graphics desktop, renders the graphics outputs of Windows applications running and displays live video overlay windows from inputs through direct HDMI or HDBaseT cables.

The Encore Video Processor (VP) is the heart of the Encore Presentation System, providing all input, output, layering and wide screen 'blending' cicuitry. Packaged as a 3RU rackmount unit, each VP can be outfitted with one, two or three Mix/Effect (M/E) boards to meet different application requirements. Models ordered with one or two M/Es can be easily upgraded by adding additional M/E boards.

Processor

Each M/E provides two independent Athena scaler channels, Barco Folsom's proprietary scaler that supports universal inputs (for both analog and digital video sources) and smooth real-time PIP movements and re-sizing based on user specified keyframes.

School

Model: MM5000-B (Rainbow) series UHD Multi-window Layout Edge-blending Processor: Input: Input Card and Signal Format Supported: Mix with various input cards capable of many and different video formats, allows for DVI-M, HDMI, Displayport, VGA, DVI, DualLink DVI, SDI, CVBS, HDBaseT, YPbPr/YCbCr, IP, and fiber signal sources. The term 'edge blending' means that the overlapped edges need to be carefully processed to blend together without appearing any brighter than other regions or at least until the brightness difference is less easily noticed by viewers.

Within an Encore system, each VP is essentiallya single destination, and multiple VPs can be combined to create advanced systems comprised of both single and blended destinations. Each VP's output board provides Program and Preview outputs in both analog and digital formats, plus interface, blending and. Two un-scaled background channels provide a high resolution backdrop that also supports seamless transitions. Down Stream Key (DSK) effects are supported by a third un-scaled high-resolution input channel.

In terms of creativity, PIPs and KEYs can be sized and positioned anywhere on screen in real-time. Z-order control is used to assign layer priorities to each PIP or KEY, and PIPS can also be linked in pairs to support transitions, or displayed (and transitioned) independently. Keys are used to provide effects such as titles and special masks.

    • 6.5Gbps serdes bandwidth for each input/output signal, FPGA line speed processing without any frame loss or drop

    • No pixel loss

      4:4:4 processing and pixel level quality maintain technology to make superb display effect

    • 4K input and output support

      Support Displayport/HDMI/Duallink DVI 4K,4K signal can be windowed, resized and positioned,support 4K projector edge blending

    • Full-featured Edge blending functions

      Black level compensation, grid based warp, fully programmable blending curve and color non-uniform correction and etc. functions are equiped

    • Powerful multi-window capability

      Fully scalable windows and powerful multi-window image processing

    • Rich input/output card support

      A complete range of input/output modules (RGB, DVI, 3G/HD-SDI, and analog formats) enables users to customize the systems to their exact requirements

    • Special DVI-M input card

      DVI-M input card can support HDMI/DVI/VGA/YPbPr/Cvbs standards in one card, make it a universal input solution

    • Modularized solution from 3U to 24U

      Up to 288 HD inputs,80 outputs, can meet any requirements of actual projects, redundant hot-swappable power supplies and Touch screen support
      MM5000-B Rainbow™ Multi-window edge blending Processor


Blending
  • Model MM5000-B (Rainbow) series
    UHD Multi-window Layout Edge-blending Processor
    Input
    Input Card and Signal Format Supported Mix with various input cards capable of many and different video formats, allows for DVI-M, HDMI, Displayport, VGA, DVI, DualLink DVI, SDI, CVBS, HDBaseT, YPbPr/YCbCr, IP, and fiber signal sources.
    DVI-M input is compatible with HDMI, DVI, VGA, YPbPr and Cvbs via passive adapter;
    Displayport 1.2/HDMI 2.0 input allows for [email protected], [email protected] and other self-defined resolutions;
    Displayport 1.1/HDMI 1.4b/Duallink DVI allows for [email protected] and other self-defined resolutions.
    Max Num. of Input Cards 9 cards /3U; 19 cards /8U; 39 cards /12U; 72 cards /24U
    Output
    Output Card and Signal Format Supported Support DVI-I, HDMI, Duallink DVI and HDBaseT.
    Input module DVI, HDMI, HDBaseT and fiber
    Max num. of Output Cards 80 channels
    Output resolution DVI/HDMI/VGA:SD([email protected])/HD([email protected])/active 3D([email protected]); Duallink DVI/HDMI: 4K([email protected])/active 3D([email protected])
    Edge-blending Function
    Edge-blending Capability Full programmable transition curves, full areas black field and light leakage compensation, pure-white and non-pure white transition curves, four edges edge-blending
    Geometric Correction Ability The 3rd generation super sub-pixel geometric correction, high - level pixel fidelity control technology, Nonlinear multi filter technology and texture compensation technology, support curved, cylinder, sphere or other irregular shaped projection screen,17X17 grid adjustment
    Other Image/Video Processing Function
    Image/Video Processing Capability Support one complete image split by multiple screen, window overlap and window across other screenoperations.
    Support all signal output in sync, and real-time echo
    Support window resize, overlap, roam, position, zoom and crop etc.
    Support On-screen display, real time display self-defined information as Chinese character or English alphabet on original image/video
    Support jointing any rectangle screens, when power down or reset, support remap output for quick restart
    Support projectors installed in any angle(optional)
    Control Spec
    Network Control RJ-45 X1,adaptive for cable up10M/100M, open API
    Serial Port Control RS-232X 2, can be controlled by the 3rd part device as switcher or screen.
    Panel Control Support visual operation via touch Pad and real-time display (optional)
    Electrical Specifications and Reliability
    Power Supply AC 100~240V / 50Hz ~ 60Hz
    Overall Power Consumption Based on the num. of input and output cards
    Working Temperature 0—70℃
    Working Humidity 15-85%
    Operating System No need specific operating system, based on pure hardware
    Startup Time Less than 3 seconds
    Weight based on the real configuration
    Accessories AC Power cable,1.5m length RS232 serial port cable, 2m length network cable with RJ45 plug,Software CD
